MOSCONI 1-100-6 ONE 100.6 6 x 120W Class AB Six-Channel High-Quality Amplifier

Ideal Amplifier For Speaker Systems in Combination With Efficient Subwoofers!

Universal 6-Channel High-Quality Amplifier
The MOSCONI ONE 100.6 is a universal 6-channel high-quality amplifier in Class AB technology. It is the ideal amplifier for speaker systems in combination with efficient subwoofers. The ONE 100.6 is equipped with a switchable FSA function. The FSA (Front Stage Adjuster) is based on an adjustable phase shift in a defined frequency range and improves the stage imaging of your front speakers. This amplifier plays powerfully and offers superior sound characteristics thanks to the analog Full MOSFET technology.

Important Information:

• 4 Ohm ST or 8 Ohm BTL – CONTINUOUS SINEWAVE SIGNAL – pure resistive load or speaker load.
• 2 Ohm ST or 4 Ohm BTL – MUSICAL SIGNAL – pure resistive load or speaker load.

Features:

• Class AB power amplifier full MOSFET
• Unregulated power supply
• High-level input with auto-sense power-on
• Cross Over with switchable High Pass or Low Pass filter
• 0 ÷ 360° Phase shift and Front Stage Adjuster (FSA)
• Remote Volume Control RTC (Optional)

Specifications:

• Colour: Black
• Finishing: Powder Coating
• Power Supply Voltage: 10 - 16V
• DC-DC Converter Typology: Unregulated – Push Pull
• Internal Fuse: 2 x 40A
• Autosense Power-On: In High-Level Mode Only
• Overall Efficiency: >60%
• Stereo Power RMS @ 4Ω: 100W x 6
• Stereo Power RMS @ 2Ω: 120W x 6
• Stereo + Bridge Power RMS @ 4Ω: 95W x 4 + 250W x 1
• Bridge Power RMS @ 4Ω: 240W x 3
• Input Sensitivity Range: 0.35 ÷ 16V
• Input Impedance (High-Level Mode): 47Ohm (Floating)
• Input Impedance (Low-Level Mode): 10kOhm (Ground Referenced)
• Input CMRR: > 80dB
• Input Interface Configuration: Fully Differential
• Low-Level Input: RCA
• High-Level Input: RCA
• Remote Control RTC (Optional): Modular Jack
• Onboard Crossover Filter Configuration: HP (ON-OFF)
• HP Filter Range: 45 ÷ 225Hz
• HP Filter Slope: 12dB/Oct
• Onboard Specific Features: FSA
• Onboard Crossover Filter Configuration: LP or HP (Always ON)
• HP & LP Filter Range: 20 ÷ 225Hz
• HP & LP Filter Slope: 12dB/Oct
• Onboard Crossover Filter Configuration: LP (ON-OFF)
• HP Filter Range: 45 ÷ 225Hz
• HP Filter Slope: 12dB/Oct
• Onboard-Specific Features: Phase Shift
• Dimensions: 310mm x 200mm x 50mm
• Weight: 2.70kg
