Victron PIN125010200 12/500 Phoenix Direct Schuko Inverter
Victron Energy Phoenix 12/500 Direct Schuko Inverter
Half a kilowatt of clean pure sine wave power from your 12V battery serious capacity in a compact inverter
Product Overview
The Victron Energy Phoenix 12/500 Direct Schuko (PIN125010200) delivers 500VA of continuous 230VAC pure sine wave output from a 12V battery bank making it the most capable model in the compact Phoenix Direct Schuko 12V range covered here. At 500VA, it comfortably handles the sustained load demands that sit beyond the reach of the 250VA and 375VA models: portable power tools, small appliances, entertainment systems, medical devices, and multiple smaller loads running simultaneously.
Built on Victron's proven full bridge plus toroidal transformer topology, the Phoenix 12/500 produces output quality equivalent to grid power essential for modern electronics, variable speed motors, and sensitive equipment that responds poorly to modified sine wave inverters. The integrated Schuko socket provides a direct 230VAC outlet without additional wiring, ECO mode keeps standby battery drain to a minimum when loads are absent or light, and the remote on/off connector allows clean system integration into caravan control panels, vehicle electrical systems, and BMS-managed installations. Fully configurable voltage protection including dynamic cutoff ensures your 12V battery bank is protected against over-discharge regardless of load conditions.
Note: This product is a standalone inverter only it does not include a battery charger. It is not suitable for connection to mains AC supply.
Key Specifications
- Input voltage: 12V DC nominal
- Output voltage: 210–245VAC (adjustable)
- Output frequency: 50Hz or 60Hz (configurable)
- Continuous output power: 500VA
- ECO mode minimum load threshold: 15W
- ECO mode sense interval: adjustable (default: every 2.5 seconds)
- Low voltage alarm: configurable trip and reset levels
- Low voltage cutoff: configurable cutoff and restart levels
- Dynamic cutoff: load-dependent cutoff level
- Short circuit protection: Yes
- Overtemperature protection: Yes
- Remote on/off: Yes (two-pole connector)
- AC outlet: Schuko (direct integrated socket)
- Battery charger included: No
- Monitoring: Input and output voltage, alarms
Features & Benefits
- 500VA continuous the most capable compact Phoenix 12V Schuko model: At 500VA, the Phoenix 12/500 handles sustained loads that the 250VA and 375VA models can't: portable power tools in use, small kitchen appliances, entertainment systems, and combinations of smaller loads running at the same time. For 12V caravan, marine, and vehicle installations where load diversity or higher individual draw is the norm, the 500VA rating provides the headroom needed.
- Pure sine wave output grid-quality AC from battery: Victron's full bridge plus toroidal transformer topology produces a pure sine wave output identical in quality to grid power. Variable speed tools, modern switching power supplies, audio equipment, medical devices, and inverter-rated appliances all operate cleanly and efficiently without the motor noise, interference, or compatibility issues that modified sine wave inverters introduce.
- Short circuit proof and overtemperature protected: A fault on the output or sustained overload won't destroy the unit. The Phoenix 12/500 shuts down cleanly and recovers automatically once conditions normalise protecting both the inverter and the connected load, and reducing the risk of damage in unattended or remote installations.
- High start-up power: LED lamp converters, halogen lamps, small power tools, and other loads with high inrush current on startup are handled cleanly. Where cheaper inverters trip or clip output during startup transients, the Phoenix maintains stable output keeping connected loads starting reliably.
- ECO mode minimise battery drain between loads: When load falls below 15W, ECO mode places the inverter in standby and samples for load reconnection every 2.5 seconds (adjustable). Standby battery draw is minimal valuable in caravan, marine, and off-grid installations where the inverter may remain switched on for hours with only intermittent load use.
- Fully configurable voltage protection: Low voltage alarm, cutoff, and restart thresholds are all user-adjustable for your specific battery chemistry and bank size. Dynamic cutoff raises the cutoff voltage under heavier loads preventing damaging deep discharge at high draw while avoiding nuisance cutoffs under light load conditions. Together, these settings give precise, chemistry-appropriate battery protection without fixed factory compromises.
- Remote on/off: Switch the Phoenix 12/500 from a caravan panel, vehicle dash switch, or BMS output without routing heavy battery cables to the switching point. The two-pole remote on/off connector accepts a low-power signal keeping installation clean and switch gear simple regardless of where the inverter is physically mounted.
- Integrated Schuko socket: A direct Schuko AC outlet is built into the unit compatible with standard Australian and European plugs. No additional socket wiring or outlet box required. Plug in and go.
- Configurable output voltage and frequency: Output voltage adjustable between 210–245VAC; frequency switchable between 50Hz and 60Hz suitable for Australian loads without modification and adaptable to other standards where needed.
- Input and output voltage monitoring with alarms: Onboard monitoring of DC input and AC output voltage with alarm outputs provides continuous system status visibility and early warning of low battery or fault conditions.
Technical Specs
| Specification | Detail |
|---|---|
| SKU | PIN125010200 |
| Brand | Victron Energy |
| Model | Phoenix 12/500 Direct Schuko |
| Input Voltage | 12V DC nominal |
| Output Voltage | 210–245VAC (adjustable) |
| Output Frequency | 50Hz or 60Hz (configurable) |
| Continuous Output Power | 500VA |
| Topology | Full bridge + toroidal transformer |
| Output Waveform | Pure sine wave |
| ECO Mode | Yes (min load threshold: 15W) |
| ECO Mode Sense Interval | Adjustable (default: 2.5 seconds) |
| Low Voltage Alarm | Configurable trip and reset levels |
| Low Voltage Cutoff | Configurable cutoff and restart levels |
| Dynamic Cutoff | Yes (load-dependent) |
| Short Circuit Protection | Yes |
| Overtemperature Protection | Yes |
| Remote On/Off | Yes (two-pole connector) |
| AC Outlet | Schuko (direct integrated) |
| Battery Charger Included | No |
| Monitoring | Input/output voltage and alarms |
Compatible With
- 12V AGM, gel, and LiFePO4 battery banks (configure low voltage settings to suit chemistry)
- Caravan and motorhome 12V DC systems requiring a compact 230VAC outlet
- Marine 12V installations for AC appliance and tool supply
- 4WD and vehicle-based auxiliary power systems with higher AC load requirements
- CPAP and PAP therapy machines requiring clean pure sine wave power
- Portable power tools and workshop equipment in mobile or off-grid setups
- Victron BMV battery monitors (input voltage monitoring and system integration)
- Victron Color Control GX and Cerbo GX (for installations requiring system-level monitoring check compatibility)
Frequently Asked Questions
How does the Phoenix 12/500 differ from the 12/375 and 12/250 models?
The 12/500 delivers 500VA continuous 33% more than the 12/375 and double the 12/250. This makes it suitable for power tools in active use, small kitchen appliances, and multiple simultaneous loads that exceed the lower-rated models' capacity. ECO mode, remote on/off, configurable voltage protection, and the integrated Schuko socket are shared across all three models.
Can I run a small power tool from this inverter?
Yes, provided the tool's continuous power draw falls within the 500VA rating and its startup inrush is within the unit's peak capacity. The Phoenix 12/500's high start-up power capability handles the inrush current of most small to medium power tools. Check your tool's watt rating and confirm it is within the inverter's capacity before use.
Does ECO mode work with all types of connected loads?
ECO mode is suited to loads that tolerate brief power interruptions phone chargers, small appliances, and battery-powered devices. For loads requiring continuous uninterrupted power computers, medical devices, or any equipment sensitive to power cycling ECO mode should be disabled so the inverter remains on continuously.
Can the remote on/off be wired to a BMS or vehicle ignition?
Yes. The two-pole remote on/off accepts a low-power signal and is compatible with BMS load-enable outputs and vehicle ignition circuits. Consult the Victron Phoenix inverter installation manual for wiring details and signal requirements before connecting.
Does this inverter include a battery charger?
No. The Phoenix 12/500 is a standalone pure sine wave inverter only and has no battery charger or AC input connection. For combined inverter and charger functionality including shore power input, PowerAssist, and UPS transfer refer to the Victron MultiPlus or MultiPlus-II range.
