Victron Energy PIN241371300 Phoenix Inverter 24/375 230V VE.Direct AU/NZ
375VA Pure Sine Wave at 24V VE.Direct, Screw Terminals, AU/NZ Ready.
Product Overview
The Victron Energy Phoenix Inverter 24/375 230V VE.Direct AU/NZ (PIN241371300) is a compact 24V pure sine wave inverter delivering 375VA of continuous 230V AC output, fitted with an Australian and New Zealand standard plug. It converts 24V leisure or house battery power into 230V AC for domestic appliances laptops, LED and halogen lighting, device chargers, and other low-draw equipment making it suited to RVs, boats, remote cabins, caravans, and camping setups where a compact, reliable 24V inverter is needed.
DC connection is via screw terminals requiring no specialist tools. There is no built-in Bluetooth monitoring and configuration are via the VE.Direct port using either the optional VE.Direct to USB interface cable (computer) or the optional VE.Direct Bluetooth Smart dongle (wireless iOS and Android devices). Both accessories are sold separately. No automatic transfer switch is included; the Victron Filax ATS is recommended for seamless AC source switchover. Pure inverter only no battery charger, no solar charger.
Key Specifications
- Part Number: PIN241371300
- Product: Phoenix Inverter 24/375 230V VE.Direct AU/NZ
- Battery Voltage: 24V
- Inverter Output: 375VA — 230V pure sine wave
- Battery Charger: None — pure inverter only
- Solar Charger: None
- Topology: Full bridge + toroidal transformer
- Output Voltage: 210–245V (configurable)
- Output Frequency: 50Hz or 60Hz (configurable)
- Plug Type: AU/NZ standard
- DC Connection: Screw terminals — no specialist tools required
- Built-In Bluetooth: No
- VE.Direct Port: Yes
- VE.Direct to USB Cable: Not included — sold separately
- VE.Direct Bluetooth Smart Dongle: Not included — sold separately
- ECO Mode: Yes — standby below pre-set load; sensitivity and duration configurable
- Dynamic Cut-Off: Yes — load-dependent battery cut-off (confirm from datasheet)
- High Start-Up Power: Yes
- Remote On/Off: Yes — remote switch connectable to two-pole connector
- LED Diagnosis: Yes
- Short Circuit Protection: Yes
- Overheating Protection: Yes
- Built-In Transfer Switch: No — external Filax ATS or MultiPlus required
- Peak/Surge Power: Not specified — confirm with supplier
- Efficiency: Not specified — confirm with supplier
- Standby Power (ECO Mode): Not specified — confirm with supplier
- IP Rating: Not specified — confirm with supplier
- Dimensions: Not specified — confirm with supplier
- Weight: Not specified — confirm with supplier
Features & Benefits
- 375VA at 24V — entry-level output for targeted loads — At 375VA, the Phoenix 24/375 is the smallest output model in the 24V Phoenix VE.Direct AU/NZ range — suited to a single primary low-draw load such as a laptop, LED lighting circuit, device chargers, or small entertainment device from a 24V house or leisure battery. For higher output or simultaneous loads, consider the 24/500 (PIN241501300) or 24/800 (PIN241801300).
- Screw Terminal DC Connection — no specialist tools — DC battery connection via standard screw terminals requires no crimping tools, cable lugs, or specialist equipment. Simplifies installation in tight spaces, lockers, and hard-to-access locations in RVs, boats, and caravans.
-
VE.Direct Port — Cable or Optional Dongle Access — The VE.Direct port provides full configuration and monitoring access via two accessory options, both sold separately:
- VE.Direct to USB Interface Cable — connects to a computer for VictronConnect configuration and monitoring.
- VE.Direct Bluetooth Smart Dongle — adds wireless access from iOS or Android smartphones, tablets, and other devices.
- Intelligent ECO Mode — Energy Conservation — Enters standby when loads are minimal and reactivates periodically to check for load increase. ECO mode sensitivity and check duration are both configurable to suit your specific usage pattern — useful for installations where the inverter is powered but loads are intermittent.
- Dynamic Cut-Off — Load-Dependent Battery Protection — Adjusts the low battery voltage disconnect threshold based on current load, protecting the 24V battery bank accurately across light and heavy load conditions.
- High Start-Up Power — The toroidal transformer surge capability handles the inrush current required to start LED lamp converters, halogen transformers, power tools, and other high-inrush loads within the inverter's rated output range.
- LED Diagnosis — On-unit LED status indicators provide quick inverter status feedback — refer to the Victron user manual for the full LED code description.
- Remote On/Off — A remote on/off switch connects easily to the two-pole connector for external inverter control from a panel, helm, or driver position.
- Full Bridge + Toroidal Transformer — Proven Reliability — Short circuit proof and protected against overheating from overload and high ambient temperature. Pure sine wave output compatible with sensitive electronics and motor-driven loads.
- AU/NZ Standard Plug — Direct connection to any standard Australian or New Zealand 10A GPO — no adapter required.
- No Built-In Transfer Switch — Pair with the Victron Filax ATS (less than 20ms) for seamless AC source switchover, or a Victron MultiPlus for combined inversion and AC input battery charging.
Technical Specs
| Specification | Detail |
|---|---|
| Part Number | PIN241371300 |
| Product | Phoenix Inverter 24/375 230V VE.Direct AU/NZ |
| Battery Voltage | 24V |
| Inverter Output | 375VA — 230V pure sine wave |
| Battery Charger | None |
| Solar Charger | None |
| Topology | Full bridge + toroidal transformer |
| Output Voltage | 210–245V (configurable) |
| Output Frequency | 50Hz or 60Hz (configurable) |
| Plug Type | AU/NZ standard |
| DC Connection | Screw terminals — no specialist tools |
| Built-In Bluetooth | No |
| VE.Direct Port | Yes |
| VE.Direct to USB Cable | Not included — sold separately |
| VE.Direct Bluetooth Dongle | Not included — sold separately |
| ECO Mode | Yes — configurable sensitivity and duration |
| Dynamic Cut-Off | Confirm from datasheet |
| High Start-Up Power | Yes |
| Remote On/Off | Yes — two-pole connector |
| LED Diagnosis | Yes |
| Short Circuit Protection | Yes |
| Overheating Protection | Yes |
| Built-In Transfer Switch | No |
| Peak/Surge Power | Not specified — confirm with supplier |
| Efficiency | Not specified — confirm with supplier |
| Standby Power (ECO) | Not specified — confirm with supplier |
| IP Rating | Not specified — confirm with supplier |
| Dimensions | Not specified — confirm with supplier |
| Weight | Not specified — confirm with supplier |
Compatible With / Goes Well With
Battery Systems:
- 24V leisure, house, and deep-cycle battery banks — lead acid (AGM, flooded, gel) and lithium
Required Accessories — Not Included (choose one):
- VE.Direct to USB Interface Cable — computer monitoring and configuration
- VE.Direct Bluetooth Smart Dongle — wireless iOS/Android device access
Transfer Switch (sold separately):
- Victron Filax Automatic Transfer Switch (less than 20ms)
- Victron MultiPlus (if AC input battery charging is also required)
Phoenix Inverter VE.Direct AU/NZ Range — Other 24V Models:
- PIN241501300 — Phoenix Inverter 24/500 (500VA)
- PIN241801300 — Phoenix Inverter 24/800 (800VA)
- PIN242121300 — Phoenix Inverter 24/1200 (1,200VA)
- PIN242161000 — Phoenix Smart 24/1600 (1,600VA, built-in Bluetooth)
Frequently Asked Questions
Does this inverter have built-in Bluetooth?
No — wireless access requires the optional VE.Direct Bluetooth Smart dongle (sold separately). Computer access uses the VE.Direct to USB interface cable (also sold separately). For built-in Bluetooth, consider the Phoenix Smart 24/1600 (PIN242161000).
What loads can a 375VA inverter realistically power?
At 375VA, this inverter suits low-draw loads — a laptop (45–90W), LED lighting, phone and device chargers, or a small entertainment device. Common household appliances including electric kettles, microwaves, and air conditioners far exceed 375VA. Always verify individual appliance wattage before connecting.
Why does this inverter use screw terminals for the DC connection?
Screw terminals require no crimping tools, cable lugs, or specialist equipment for the battery connection — simplifying installation in the tight spaces commonly encountered in RVs, boats, and caravans. Field servicing and reconnection are also straightforward.
Does this inverter include a transfer switch?
No. The Victron Filax ATS (less than 20ms switchover) is recommended for installations requiring transfer to a generator or shore power source. For combined inversion and battery charging from AC input, a Victron MultiPlus is the more complete solution.
How does the 24/375 compare to the 24/500 in the Phoenix range?
Both use the same Phoenix VE.Direct platform with identical features. The 24/375 is the entry-level model at 375VA; the 24/500 (PIN241501300) delivers 500VA. Choose the 24/375 when your maximum load is well within 375VA; choose the 24/500 if you need headroom for slightly higher or simultaneous loads.
