Victron Energy BPC241242012 Blue Smart IP22 Charger 24/12(1) 230V AU/NZ

Victron Energy Blue Smart IP22 24/12(1) Professional 24V Bluetooth Charger for Workshop, Vehicle, Boat and Classic.

---

Product Overview

The Victron Energy Blue Smart IP22 24/12(1) (BPC241242012) is a professional single-output 24V battery charger delivering 12 amps with up to 94% conversion efficiency fitted with an Australian and New Zealand standard plug for direct mains connection without adapters. Designed for workshop and vehicle charging rather than permanent panel installation, the Blue Smart IP22 brings Bluetooth connectivity, a 6-stage adaptive charge algorithm, and VE.Smart Network support to the portable charger category a meaningful step above basic plug-in chargers that offer none of these capabilities.

At 12A output, the BPC241242012 is appropriately sized for 24V batteries from approximately 60Ah to 200Ah covering the range from motorcycle and small vehicle batteries through to mid-sized house banks in caravans, campervans, and smaller marine vessels. The 40-cycle charge history log, 11 status LEDs, NIGHT and LOW output modes, and Battery Recovery function for deeply discharged batteries round out a feature set that makes this charger a useful tool beyond simple top-up charging. The single AU/NZ plug configuration means it is ready to use from the mains immediately though note that the DC output cable is not included and must be sourced separately.

---

Key Specifications

• Part Number: BPC241242012
• Charger Type: Portable single-output AC-DC battery charger
• Output Voltage: 24V
• Output Current: 12A
• Output Configuration: (1) — single output
• Input Voltage: 230V AU/NZ (AU/NZ standard plug)
• Efficiency: Up to 94%
• Standby Power (Fully Charged): 0.5W
• Charge Algorithm: Adaptive 6-stage
• Battery Compatibility: Lead acid (all types), Li-ion (LiFePO₄ and others)
• Battery Recovery Function: Yes — initiates charging on deeply discharged batteries
• NIGHT Mode: Yes — reduces output current for quiet operation
• LOW Mode: Yes — reduces output current; automatic or manual
• Bluetooth: Built-in (VictronConnect app — iOS and Android)
• VE.Smart Network: Yes
• Charge History: 40-cycle log with detailed statistics
• Status LEDs: 11
• Parallel Operation: Yes — up to 10 chargers synchronised
• Optional: Battery voltage and temperature compensation, current sensing
• IP Rating: IP22
• DC Cable: Not included — must be sourced separately
• Dimensions: Not specified — confirm with supplier
• Weight: 1.6 kg

---

Features & Benefits

• Up to 94% Efficiency — 0.5W Standby — At 94% conversion efficiency, the BPC241242012 generates significantly less heat than lower-efficiency equivalents at the same output current — reducing thermal stress on the charger and battery, and cutting energy consumption during charging. When the battery is fully charged, standby draw drops to 0.5W — the charger can remain connected indefinitely without meaningful energy waste or risk of overcharge.
• Adaptive 6-Stage Charge Algorithm — Six managed stages covering the full charge and maintenance lifecycle. Bulk delivers maximum current for rapid recharge. Absorption holds at the correct voltage while current tapers, adapting duration to discharge depth. Recondition recovers sulphated lead acid batteries. Float safely maintains a fully charged battery. Storage Mode reduces float voltage after 24 hours without discharge to minimise gassing and plate corrosion during layup — with a weekly equalisation pulse to prevent stratification and sulphation. The sixth stage (confirm Refresh from datasheet) completes the cycle management.
• Battery Recovery Function — Initiates a controlled low-current recovery charge on batteries that have discharged so deeply that a standard charger would refuse to recognise them. This is a practical feature for workshop, classic vehicle, and seasonal-use battery applications where batteries are frequently found in deeply discharged states after extended storage.
• NIGHT and LOW Output Modes — NIGHT mode reduces the charge current to eliminate fan or cooling noise during overnight charging in living or sleeping spaces — relevant for caravan, motorhome, and boat cabin installations. LOW mode reduces output current further, operable in automatic or manual mode. Useful when charging sensitive battery types or in scenarios where heat generation needs to be minimised.
• Fully Programmable Charge Algorithm — Absorption, float, and storage voltages are all user-adjustable via the VictronConnect Bluetooth app. Expert mode unlocks advanced parameters for non-standard battery specifications, custom charge profiles, and integration with specific battery manufacturers' recommended setpoints.
• Li-ion Battery Compatible — A dedicated Li-ion charge algorithm ensures correct charging for lithium iron phosphate and other compatible Li-ion chemistries. The algorithm adapts current and voltage to the specific requirements of Li-ion cells rather than applying a lead acid profile.
• Built-In Bluetooth — VictronConnect App — Monitor charge status in real time, adjust settings, review charge history, and update firmware wirelessly from any iOS or Android device. No data cable or separate interface required — direct Bluetooth access from your phone.
• 40-Cycle Charge History Log — Stores detailed statistics for the last 40 charge cycles — including voltages, currents, charge times, and cycle outcomes. Useful for diagnosing battery health trends, identifying underperforming batteries, and tracking service intervals in workshop and fleet applications.
• 11 Status LEDs — Visual charge status indication across all stages and modes without requiring a phone or app connection. Charge progress, mode selection, fault conditions, and completion state are all readable at a glance on the charger face.
• VE.Smart Network — Optimised Parallel Charging — Connect up to 10 Blue Smart IP22 chargers in a VE.Smart Network for synchronised charging. All chargers in the network transition between charge stages simultaneously, preventing stage conflicts across parallel units. Optional battery voltage and temperature sensing data can be shared across the network for optimised charge decisions from all connected chargers.
• Optional Battery Voltage and Temperature Compensation — When an optional external voltage or temperature sensor is connected, the charger uses actual battery terminal voltage and temperature for charge stage decisions — compensating for cable voltage drop and adjusting setpoints based on real battery temperature. Extends the accuracy of charging beyond what a charger-terminal-only measurement can provide.
• Overheating Protection — Output current automatically reduces as charger temperature rises, protecting internal components without shutting down entirely. Charging continues at a reduced rate in hot environments rather than cutting off abruptly.
• 230V AU/NZ Plug — Ready to Use — Australian and New Zealand standard mains plug allows direct connection to any standard 10A GPO. No adapter required for Australian use.

⚠️ DC Output Cable Not Included — The DC cable connecting the charger to the battery is not supplied. Ensure the correct DC cable, connector type, and cable rating are sourced before use. Confirm the required DC output connector type from the product datasheet or retailer before ordering the cable separately.

---

Technical Specs

---

Compatible With / Goes Well With

Primary Applications:

• Workshop battery charging — 24V vehicle, equipment, and plant batteries
• Classic cars and motorcycles with 24V battery systems
• Caravans and motorhomes — 24V house battery charging from mains or shore power
• Smaller marine vessels — 24V battery charging at marina or on shore
• Seasonal-use vehicles and equipment with batteries subject to deep discharge during storage

Battery Types:

• All lead acid chemistries — flooded, AGM, gel (24V)
• Li-ion including LiFePO₄ (24V) — confirm correct profile selection via VictronConnect app

VE.Smart Network Pairing:

• Up to 10 Blue Smart IP22 chargers for synchronised parallel charging
• Optional: Victron Smart Battery Sense (wireless voltage and temperature sensing)
• Optional: Victron BMV-712 Smart (battery monitor with wireless sensing for VE.Smart Network)

Accessories Required:

• DC output cable — not included, must be sourced separately (confirm correct connector type and cable rating from datasheet)

---

Weight

1.6 kg

---

Frequently Asked Questions

Why is the DC cable not included and what cable do I need?

Victron ships the Blue Smart IP22 without the DC output cable to allow users to select the appropriate cable length, gauge, and connector type for their specific installation. Confirm the correct DC output connector type from the Victron datasheet for BPC241242012, then source a cable rated for at least 12A continuous at 24V with the correct connector. Consult your retailer or Victron documentation for the recommended cable specification.

What is the difference between IP22 and IP43 and does it matter for my application?

IP22 means the charger is protected against solid objects larger than 12.5mm and dripping water when tilted up to 15° — suitable for workshop, indoor, and protected vehicle use. IP43 (as on the Phoenix Smart range) adds protection against water spray up to 60° from vertical, making it more appropriate for marine engine rooms and damp outdoor spaces. If your installation is exposed to water spray or high humidity, the Phoenix Smart IP43 range is the correct choice.

What is the NIGHT mode and when should I use it?

NIGHT mode reduces the charge current to eliminate fan or cooling noise, making it suitable for overnight charging in living spaces — caravan interiors, motorhome habitation areas, and boat cabins where charger noise would be disruptive. Select NIGHT mode manually via the mode button or configure automatic activation via the VictronConnect app.

Can I use this charger to recover a completely flat 24V battery?

Yes. The Battery Recovery function initiates a low-current recovery charge on deeply discharged batteries that a standard charger would not recognise. This is particularly useful for seasonal-use vehicle batteries, stored classic vehicle batteries, and any 24V battery that has discharged below the charger's normal detection threshold.

Can I connect multiple Blue Smart IP22 chargers in parallel for faster charging?

Yes — up to 10 Blue Smart IP22 chargers can be paired in a VE.Smart Network for synchronised parallel charging. All units transition between charge stages simultaneously. For large battery banks where 12A per charger is insufficient, this provides a scalable way to increase total charge current in a managed, synchronised configuration.
