MOSCONI 1-90-8-DSP ONE 90.8-DSP 8-Channel High-Quality AB Class Amplifier

Ideal Amplifier For Speaker Systems & Efficient Subwoofers!

8-Channel High-Quality DSP Amplifier
The MOSCONI ONE 90.8 DSP is a universal 8-channel high-quality amplifier in Class AB technology and an integrated digital sound processor. It is the ideal amplifier for speaker systems and/ or efficient subwoofers. The digital 8-channel sound processor allows you to adjust your car's Hi-Fi system perfectly via PC software. In addition to an extensive active crossover, equalizer, and delay correction, various special filters are available. For system expansion, the ONE 90.8 DSP has a processed preamplifier output. Here you can easily connect the "Line IN" of another mono or stereo amplifier.

Features:

• Class AB power amplifier full MOSFET
• Unregulated power supply
• High-level input with auto-sense power-on
• Remote Volume Control DSP-RCD or DSP-RC MINI (Optional)
• On-board DSP + 2 digitally processed line outputs

Specifications:

• Colour: Black
• Finishing: Powder Coating
• Power Supply Voltage: 10 - 16V
• DC-DC Converter Typology: Unregulated – Push Pull
• Internal Fuse: 2 x 40A
• Autosense Power-On (High Level Only): OFF-BTL-SE
• Overall Efficiency: >60%
• REM Output: 10 - 16V (100mA)
• Stereo Power RMS @ 4Ω: 90W x 8
• Promiscuous Mode Power RMS @ 4Ω 85W x 4 + 250W x 2 (BTL)
• Bridge Power RMS @ 4Ω: 240W x 4
• Stereo Power RMS @ 2Ω: 120W x 8 (BTL Not Allowed)
• Low Level + High-Level Input Sensitivity Range: 0.8 ÷ 17V
• Auto-Fading Between Inputs: Yes
• Signal Mix Capability: Yes
• Low-Level Input: RCA
• High-Level Input: RCA
• Pre Output: RCA (CH 7-8) DSP Processed
• PC Connection: USB
• Remote Control (Optional): Modular Jack
• Bluetooth (Optional): MOS_BTM
• Gain Level For Each Channel: -115 ÷ 6dB
• Parametric Equalizer Bands (CH 1-2): 30
• Parametric Equalizer Bands (CH 3-4): 25
• Parametric Equalizer Bands (CH 5-6-7-8): 9
• Preset: 4 Available
• HP Frequency Range For Each Channel: 10 ÷ 20000Hz
• LP Frequency Range For Each Channel: 10 ÷ 20000Hz
• HP & LP Filter Slope For Each Cell: 6-12dB
• HP & LP Filter Slope if Cascated (CH 1-4): Up to 60dB
• HP & LP Filter Slope if Cascated (CH 5-8): Up to 48dB
• Band Pass: Allowed
• Variable «Q» Factor: 0.5 ÷ 40
• Time Delay: 0 ÷ 15ms (Steps of 0.02ms)
• Phase Inversion For Each Channel: 0/180°
• Dimensions: 300mm x 200mm x 50mm
• Weight: 2.60kg
