Hertz DP 4.400 Dieci Power 1000W 4-Channel Amplifier

An Audio Powerhouse Designed to Elevate Your Car Audio Experience to Unprecedented Heights!

Dieci Power 1000W 4-Channel Amplifier
Hertz DIECI POWER amplifier DP 4.400 is an audio powerhouse designed to elevate your car audio experience to unprecedented heights. Boasting High-Resolution Audio Certification, this amplifier delivers an impressive frequency response of 10 Hz to 45 kHz, ensuring that every nuance of your music is faithfully reproduced with crystal-clear precision.

Despite its compact size, the DP 4.400 packs a punch with its maximum power output, featuring fully bridgeable 4-channel Class-AB amplification and 2Ω stability. This innovative design allows for a potent audio performance without sacrificing space, making it an ideal choice for those seeking uncompromised sound in a limited footprint.

The amplifier's aesthetics are as impressive as its performance. An elegant status LED, solid machined terminal block, and a removable top panel that safeguards controls and connections contribute to a sleek and sophisticated design that seamlessly integrates into any car interior.

Universal compatibility is a key feature of the DP 4.400, offering an operating supply voltage ranging from 6.5 to 16.5 V and speaker-in input sensitivity from 1.6 to 40 Vrms. The integrated Universal Speaker Simulator enhances versatility, ensuring optimal performance with a wide range of audio sources.

Experience high-noise rejection with the balanced input circuitry of the Pre-in and Speaker-in, allowing for clean and interference-free signal transmission. The full set of controls, including adjustable input levels, high/low-pass crossover filters (50-4000Hz 12dB/Oct.), and bass boost, provides users with the flexibility to fine-tune the audio to their preferences.

Convenience meets intelligence with the Automatic Remote Turn-On/Off feature, seamlessly triggered by OEM radio speaker outputs. This ensures hassle-free operation and an efficient power management system.

Whether utilizing Speaker-In or Pre-In level inputs, the DP 4.400 offers full-range pre-outs, providing further flexibility in system configuration. Elevate your car audio system with the Hertz DIECI POWER Amplifier DP 4.400 – where power, precision, and style converge for an unparalleled listening experience on the road.

Features:

• High-Resolution Audio Certification: Hi-Res Audio certification featuring a frequency response of 10 Hz – 45 kHz.
• Maximum Power in Compact Size: fully bridgeable 4-channel Class-AB 2Ω stable power outputs in a small and compact design.
• Attractive Design: elegant status LED, solid machined terminal block, and removable top panel to protect controls and connections.
• Universal Compatibility: operating supply voltage from 9 to 16.5 V and speaker-in input sensitivity from 1.6 to 40 Vrms with integrated Universal Speaker Simulator.
• High-noise rejection: Pre-in and Speaker-in featuring balanced input circuitry.
• Full set of controls: adjustable input levels, high/low-pass crossover filters (50-4000Hz 12dB/Oct.), and bass boost to fine-tune the sound according to your preferences.
• Automatic Remote Turn-On/Off: driven by OEM radio speak
• Full-Range pre-outs: available both when using Speaker-In and Pre-in level inputs.

Specifications:

• General:
  Channels: 4 - 3 - 2
  Nominal Power Supply Voltage (Fuse): 11 ÷ 15 VDC (2 x 25 A)
  Operating Power Supply Voltage: 6.5 ÷ 16.5 VDC
  Idling Current: 0.85 A
  Standby Current Draw: 10 uA
  Consumption, MIN Load Impedance (Max Musical Power): 30 A
  Remote IN: 4 ÷ 15 VDC (1.5 mA)
  ART - Automatic Remote Turn On/Off From SPK-IN (BTL Radio Only): 1.5 VDC
  Efficiency: 60%
  Distortion - THD @ 100 Hz, 70% Rated Power: 0.01%
  Damping Factor @ 1 kHz, 1W: 130
  Bandwidth @ -3 dB: 10Hz ÷ 45kHz
  S/N Ratio (A-Weighted @ 1 V Input): 101 dBA
  Minimum Load Impedance:, @ 4 Ch: 2 Ω, @ 3 Ch: 2 Ω + 2 Ω + 4 Ω, @ 2 Ch: 4 Ω
  Adjustable Crossovers: Yes
• Output Power:
  Output power (RMS) @ 1% THD:
  4Ch @ 4Ω 75 W x 4
  4Ch @ 2Ω 105 W x 4
  3Ch @ 4Ω 75 W x 2 + 210 W x 1
  3Ch @ 2Ω / 4Ω 105 W x 2 + 210 W x 1
  2Ch @ 4Ω 210 W x 2
  Output Power (RMS) @ 14.4 VDC, THD 10%:
  4Ch @ 4Ω 90 W x 4
  4Ch @ 2Ω 125 W x 4
  3Ch @ 4Ω 90 W x 2 + 250 W x 1
  3Ch @ 2Ω / 4Ω 125 W x 2 + 250 W x 1
  2Ch @ 4Ω 250 W x 2
  Total Power: 1000 W
• Inputs / Filters:
  Inputs: Pre-In / Speaker-In
  Pre-Out: Full Range (Front)
  Pre-In Sensitivity: 0.32 ÷ 8 VRMS
  Speaker-In Sensitivity: 1.6 ÷ 40 VRMS
  Front Ch Hi-Pass: Full / 50-4000Hz 12dB/Oct.
  Front Ch Lo-Pass: Full / 50-4000Hz 12dB/Oct.
  Rear Ch Hi-Pass: Full / 50-4000Hz 12dB/Oct.
  Rear Ch Lo-Pass: Full / 50-4000Hz 12dB/Oct.
  Bass Boost: 50Hz 0 ÷ 9 dB
• Physical Specifications:
  Weight: 2.88kg
