DB Drive DX-S694 | 6x9" 4-Way Car Speakers

Professional 6x9" 4-way speakers delivering superior sound quality with advanced multi-driver design for exceptional audio performance.

Product Overview

The DB Drive DX-S694 6x9" 4-Way Speakers represent advanced automotive audio engineering, combining multiple precision drivers in a space-efficient package designed for superior sound reproduction. These professional-grade speakers feature dual 0.75" aluminum dome tweeters, a 2" PEI midrange driver, and injection-molded PP composite woofer cone to deliver exceptional clarity across the entire frequency spectrum from 40Hz to 21kHz.

Built with optimized frequency bandwidth design and integrated crossover network, the DX-S694 speakers provide smooth frequency transitions and natural sound reproduction perfect for Australian vehicles. The advanced 4-way configuration ensures precise sound staging and enhanced detail retrieval, making these speakers ideal for both factory system upgrades and custom audio installations.

Key Specifications

• Speaker configuration: 6x9" (6"x9") 4-way multi-driver design
• Maximum power handling: 260W dynamic power
• Nominal power handling: 85W continuous
• Frequency response: 40Hz - 21kHz extended range
• Impedance: 4Ω for optimal amplifier matching
• Sensitivity: 96dB for high efficiency
• Advanced multi-driver configuration with integrated crossover
• 12-month manufacturer warranty

Features & Benefits

Advanced Multi-Driver Design - Dual 0.75" aluminum dome tweeters with optimized off-axis response deliver crystal-clear highs with expanded soundstage, while dedicated 2" PEI midrange driver ensures precise vocal reproduction and enhanced detail retrieval.

Professional Woofer Performance - Injection-molded PP composite cone with rubber surround and oversized 1.5" voice coil provides deep, accurate bass response with enhanced thermal capacity for consistent high-volume performance without distortion.

Precision Engineering - Forged motor plates with linear gauss geometry and ferrite oxide magnet deliver improved sound clarity and efficiency, while stamp-cast steel basket construction minimizes unwanted vibrations for accurate sound reproduction.

Optimized Frequency Management - Integrated 6dB crossover network ensures smooth frequency transitions between drivers, delivering natural sound reproduction and eliminating the need for external crossover components.

Advantages & Limitations

Advantages:

• Advanced 4-way design with dual aluminum tweeters
• High power handling (260W max) for dynamic performance
• Extended frequency response (40Hz-21kHz)
• High sensitivity (96dB) for efficient amplifier use
• Integrated crossover eliminates external components
• 6x9" size fits most factory locations

Limitations:

• Complex multi-driver design may require quality amplification
• 12-month warranty shorter than some premium brands
• Higher cost than simple 2-way alternatives
• May require professional installation for optimal performance

Technical Specs

• Configuration: 6x9" 4-way coaxial speakers
• Tweeters: Dual 0.75" aluminum dome with optimized off-axis response
• Midrange: 2" PEI driver with wide bandwidth tuning
• Woofer: Injection-molded PP composite cone with rubber surround
• Voice coil: 1.5" oversized with enhanced thermal capacity
• Motor: Forged plates with linear gauss geometry
• Magnet: Ferrite oxide with optimized motor force
• Basket: Stamp-cast steel construction
• Crossover: Onboard 6dB frequency division network
• Power: 260W max, 85W nominal
• Frequency: 40Hz - 21kHz extended response
• Impedance: 4Ω
• Sensitivity: 96dB

Frequently Asked Questions

What's the advantage of 4-way over 2-way speakers? The 4-way design with dual tweeters and dedicated midrange driver provides superior sound staging, enhanced detail, and more precise frequency reproduction compared to simpler 2-way systems.

Will these fit standard 6x9" factory locations? Yes, the DX-S694 is designed to fit standard 6x9" factory mounting locations, though depth and clearance should be verified before installation.

Do I need a powerful amplifier for these speakers? While they'll work with factory head units, a quality amplifier will unlock their full 260W potential and provide the best sound quality from the advanced 4-way design.

Compatible With / Goes Well With

• Car amplifiers (4Ω load compatible)
• Factory and aftermarket head units
• Professional car audio installation services
• Sound deadening materials for enhanced performance
• Aftermarket wiring harnesses and adapters
• Speaker mounting brackets and grilles
