Aerpro AX9670PK 6.8" Head Unit Kit Ford Territory SZ MK2 2015-2016

Aerpro AX9670PK 6.8" Multimedia Head Unit Upgrade Kit Ford Territory SZ MK2

A fully matched upgrade kit for the Ford Territory SZ MK2 Gloss (2015-2016), the AX9670PK combines a 6.8" wireless CarPlay and Android Auto multimedia receiver with a vehicle-specific piano black fascia installation kit including an HVAC controller, reverse camera and subwoofer retention lead, plus a 720P AHD surface mount camera, all in one box.

Product Overview

The AX9670PK is Aerpro's complete head unit upgrade solution engineered for the Ford Territory SZ MK2 Gloss from 2015-2016. It is supplied as a three-component kit comprising the Aerpro 6.8" multimedia receiver, the vehicle-specific installation kit tailored to the Territory SZ MK2 dashboard profile, and a 720P AHD surface mount camera. No additional accessories need to be sourced for a standard installation. The vehicle-specific installation kit includes a piano black fascia kit, an HVAC controller and steering wheel control interface, a reverse camera and subwoofer retention lead, a steering wheel control interface, and a universal SWC patch lead, ensuring factory HVAC, steering wheel controls, factory reverse camera, and factory subwoofer output are all retained after installation.

The 6.8" capacitive touchscreen at 1024x600 resolution supports wireless and wired Apple CarPlay and Android Auto, Bluetooth V5 with HFP 1.6 HD Voice, A2DP audio streaming, AVRCP media control, and PBAP phonebook access. Both internal and external microphone options are provided, with the external microphone and mount included in the head unit box. Audio performance is delivered via 4 x 50W maximum output, a 13-band graphic EQ covering 32Hz through to 16kHz, time alignment, subwoofer low-pass filter control, and 4V 6-channel RCA preouts covering front, rear, and subwoofer channels for external amplifier integration. Dual rear USB inputs support CarPlay and Android Auto on USB 1 and media playback on USB 2, each at 5V/1.5A charging. Dual AHD 720P-compatible camera inputs accept the included surface mount camera and an additional second camera simultaneously.

The included 720P AHD surface mount camera uses a Sony 225 1/3" CMOS sensor with a 150-degree lens angle and is mountable as a front, rear, or reverse camera. It is supplied with 6 metres of RCA video cable with an in-line reverse trigger wire. Head Unit Upgrade Kits can vary between vehicle models. Use the Aerpro What Fits Your Car Guide at aerpro.com to confirm compatibility with your specific vehicle before purchase.

Features & Benefits

Complete Vehicle-Specific Upgrade Kit for Ford Territory SZ MK2 2015-2016: The AX9670PK includes all components required for a complete installation in the Ford Territory SZ MK2 Gloss from 2015-2016 without additional accessory sourcing. The vehicle-specific installation kit covers the fascia, HVAC controller, SWC interface, reverse camera and subwoofer retention lead, and patch lead requirements of the Territory SZ MK2 platform.

HVAC Controller and Steering Wheel Control Interface: The vehicle-specific installation kit includes a combined HVAC controller and steering wheel control interface module that retains the factory climate control functionality and steering wheel audio controls after the head unit is replaced. This is a critical vehicle-specific requirement for the Territory SZ MK2 addressed within the kit without additional modules.

Reverse Camera and Subwoofer Retention Lead: The vehicle-specific installation kit includes a dedicated retention lead that retains both the factory reverse camera and the factory subwoofer output after the new head unit is installed. The factory reverse camera continues to display on the 6.8" screen when reverse gear is selected, and the factory subwoofer remains operational through the new head unit's signal path.

Piano Black Fascia Kit for Territory SZ MK2 Dashboard Integration: The included piano black fascia kit is designed specifically for the Ford Territory SZ MK2 Gloss (2015-2016) dashboard profile, providing a premium gloss finish that integrates with the interior trim of the Territory SZ MK2. The piano black finish of the AX9670PK distinguishes it from the satin black fascia of the AX9660SK which suits the earlier SZ MK1.

6.8" Capacitive Touchscreen at 1024x600: The 6.8" capacitive touchscreen delivers a large, responsive display with 1024x600 resolution for clear navigation of maps, media, and settings, well suited to the dashboard opening of the Territory SZ MK2.

Wireless and Wired Apple CarPlay and Android Auto: Both Apple CarPlay and Android Auto operate wirelessly for hands-free smartphone integration, or via wired USB connection for simultaneous charging. On first wireless connection, a one-time pairing via Bluetooth and Wi-Fi is required before subsequent connections become automatic.

Bluetooth V5 with HFP 1.6 HD Voice: Bluetooth V5 supports A2DP high-quality audio streaming, AVRCP media control, PBAP phonebook access, and HFP 1.6 HD Voice quality hands-free calling. Both an internal microphone and an external microphone with mount are included, allowing the external microphone to be positioned optimally in the cabin.

13-Band Graphic EQ with Time Alignment: The 13-band EQ covers 32Hz, 63Hz, 125Hz, 250Hz, 500Hz, 1kHz, 2kHz, 4kHz, 8kHz, 10kHz, 12kHz, 14kHz, and 16kHz for precise acoustic tuning, complemented by time alignment and a subwoofer low-pass filter for a complete onboard tuning toolkit.

4V 6-Channel RCA Preouts: Six RCA preamp channels at 4V covering front, rear, and subwoofer outputs allow external amplifiers to be added to the system with a high-output, low-noise signal. Subwoofer level control is also provided directly from the head unit.

720P AHD Surface Mount Camera Included: The included 720P AHD surface mount camera uses a Sony 225 1/3" CMOS sensor, a 150-degree lens angle, optional parking guidelines, and an IP67 waterproof rating. It can be mounted as a front, rear, or reverse camera and connects to the head unit via the included 6-metre RCA cable with in-line reverse trigger wire.

Dual AHD 720P Camera Inputs: Two independent AHD 720P-compatible camera inputs allow the included surface mount camera and a second camera to be connected simultaneously, supporting configurations such as front and reverse cameras.

6-Colour Button Illumination: The key illumination is selectable across six colours including red, yellow, green, blue, purple, and white, allowing the button lighting to be matched to the Territory SZ MK2 interior.

AM/FM Tuner with RDS: FM tuning covers 87.5-108.0MHz with 18 presets, and AM covers 522-1710kHz with 12 presets, with RDS support for station and track information display.

Technical Specs

What's in the Box

Aerpro 6.8" Multimedia Receiver:

• 1x 6.8" Multimedia Double DIN Head Unit
• Double DIN Metal Frame and Mounting Hardware
• Head Unit Plastic Trim
• Wiring Harness with ISO Connection
• 3 Wire Learning SWC Lead
• External Microphone with Mount
• GPS Antenna with Adhesive Pad
• QR Digital Manual Leaflet

Vehicle Specific Installation Kit:

• Piano Black Fascia Kit
• HVAC Controller and Steering Wheel Control Interface
• Reverse Camera and Subwoofer Retention Lead
• Steering Wheel Control Interface
• Universal Patch Lead

720P AHD Surface Mount Camera:

• 720P AHD Surface Mount Camera (wired)
• 6-Metre Video Cable (RCA) with In-Line Reverse Trigger

Compatible With

The AX9670PK is engineered for the Ford Territory SZ MK2 Gloss from 2015-2016. Head Unit Upgrade Kits can vary between vehicle models. Use the Aerpro What Fits Your Car Guide at aerpro.com to confirm compatibility with your specific vehicle before purchase. The 4V 6-channel RCA preouts are compatible with most aftermarket amplifiers requiring front, rear, and subwoofer signal inputs. The dual AHD 720P camera inputs are compatible with most aftermarket AHD 720P and standard composite cameras in addition to the included surface mount camera.

Frequently Asked Questions

What is the difference between the AX9670PK and the AX9660SK?

Both the AX9670PK and AX9660SK are complete head unit upgrade kits for the Ford Territory sharing the same head unit specification, HVAC controller, reverse camera and subwoofer retention lead, and 720P AHD surface mount camera. The key differences are vehicle generation and fascia finish. The AX9660SK suits the Territory SZ MK1 (2011-2014) and includes a satin black fascia, while the AX9670PK suits the Territory SZ MK2 Gloss (2015-2016) and includes a piano black fascia. Use the Aerpro What Fits Your Car Guide at aerpro.com to confirm which kit is correct for your specific vehicle.

Does the AX9670PK retain the factory Ford Territory SZ MK2 HVAC climate control?

Yes. The vehicle-specific installation kit includes a combined HVAC controller and steering wheel control interface module that retains the factory climate control functionality after the head unit is replaced. This module is specific to the Territory SZ MK2 and is included within the kit, meaning no additional HVAC retention module needs to be sourced separately for a standard installation.

Does the AX9670PK retain both the factory reverse camera and the factory subwoofer?

Yes. The vehicle-specific installation kit includes a dedicated retention lead that retains both the factory reverse camera and the factory subwoofer output. The factory reverse camera continues to display on the 6.8" screen when reverse gear is selected, and the factory subwoofer remains operational through the new head unit's signal path, both via the single included retention lead.

Can the included 720P AHD camera be used as a front camera instead of a reverse camera?

Yes. The included 720P AHD surface mount camera can be installed and configured as a front, rear, or reverse camera depending on the installation requirement. It connects to either of the head unit's two AHD 720P-compatible camera inputs via the included 6-metre RCA cable with in-line reverse trigger wire. If used as a front camera, the reverse trigger wire would not be connected and the camera would need to be activated through an alternative trigger or manual input method depending on the head unit's camera activation settings.

Can external amplifiers be connected to the AX9670PK?

Yes. The head unit provides 4V 6-channel RCA preouts covering front, rear, and subwoofer channels, allowing external amplifiers to be connected for higher output power or a dedicated subwoofer channel. The 4V output voltage provides a strong, low-noise signal compatible with most aftermarket car audio amplifiers. Subwoofer level control is also available directly from the head unit for convenient bass adjustment without accessing the amplifier directly.
